Industrial Pipe Support Clamps & Brackets

Stainless Steel Pipe Support Clamps are robust, corrosion-resistant structural clamps designed for securely suspending and supporting pipes, tubes, conduits, and mechanical lines from overhead structures, walls, or frameworks. Unlike cushioned or lined variants, these clamps feature a direct metal-to-pipe contact interface, prioritizing maximum strength, rigidity, and durability in demanding environments. They are fundamental components in industrial, marine, chemical, and food-grade piping systems.

Technical Specifications：

Material: AISI 304, 316, or Zinc Plated Carbon Steel.

Size Range: Suitable for pipe diameters from 1/2" to 12" (or specify your range).

Features: Anti-vibration lining, high load capacity, and corrosion resistance

Features of clamp for pipe support

1. Material & Finish

Primary Material: Manufactured from Austenitic Stainless Steel, primarily:

Grade 304 (A2/AISI 304): The standard grade for excellent all-around corrosion resistance in most environments.

Grade 316 (A4/AISI 316): Contains molybdenum for superior resistance to chlorides, acids, and saltwater, making it ideal for marine and chemical processing applications.

Finish: Typically supplied with a mill finish (2B) or a brushed/polished finish. Can be electropolished or passivated for enhanced corrosion resistance and a clean, easy-to-sanitize surface, which is critical for hygienic industries.

2. Structural Design

Two-Piece Construction: Consists of a top saddle and a bottom saddle that form a complete ring around the pipe when assembled.

Full-Circle Restraint: Provides 360-degree support, firmly gripping the pipe to prevent lateral movement, sagging, or uplift.

Integrated Hanging Point: The top half features a built-in loop, eyelet, or flat tab with a hole for attaching to a threaded rod, all-thread, channel, or beam clamp.

Fastening Mechanism: The two halves are joined by two bolts (one on each side), ensuring even clamping force and ease of installation. Bolts and nuts are typically stainless steel to match.

3. Key Characteristics (Unlined)

No Rubber/Cushion: The inner surface is bare, polished stainless steel.

High Mechanical Strength: Designed to handle significant static and dynamic loads.

Rigid Connection: Provides a fixed, non-isolating support point.

FAQ of Clamp for Pipe Support

Q: What is the maximum load capacity for these pipe support clamps?

A: Our pipe support clamps are engineered for heavy-duty use. The safe working load depends on the diameter and material thickness, with our largest sizes capable of supporting up to 12.5 kN. Technical data sheets are available for specific calculations.

Q: Are these supports adjustable for different heights?

A: Yes, when used with threaded rods or strut channels, our clamps allow for precise vertical and horizontal adjustments to ensure proper pipe gradient and alignment.

Q: Can you provide customized support clamps for non-standard pipe sizes?

A: Absolutely. As a direct manufacturer, we can customize the band width, thickness, and diameter to meet unique engineering requirements or specific industrial standards.
