Bolt Hose Clamp with Rubber

This stainless steel bolt hose clamp with rubber is a specialized and high-performance hose clamp designed for demanding applications where a secure, leak-proof, and vibration-resistant seal is critical.

Material of bolt hose clamp

W4 - All parts stainless steel 201,304 or 316 with rubber

Featurers of bolt hose clamp

Stainless Steel Band:

Material: Typically made from high-quality 304 or 316 stainless steel, which provides exceptional resistance to rust, corrosion, and chemical degradation. This makes it ideal for use in harsh environments, including marine, automotive, industrial, and outdoor applications.

Heavy Duty Construction: The band is thicker and stronger than standard worm-drive clamps, allowing it to exert and withstand much higher clamping forces without buckling or slipping.

Integrated Rubber Sleeve/Strip:

This is the defining feature that sets it apart from standard all-metal clamps. A layer of rubber (often EPDM or Nitrile) is bonded to the inner surface of the stainless steel band.

Functions of the Rubber:

Superior Seal: The rubber conforms perfectly to the irregularities of the hose and fitting, creating an excellent seal that prevents leaks of fluids, gases, or dust.

Vibration Dampening: It absorbs shocks and vibrations, preventing the clamp from loosening over time—a common issue with all-metal clamps in dynamic applications.

Surface Protection: The soft rubber cushion protects the hose from being cut, abraded, or damaged by the sharp edges of the metal band, thereby extending the life of the hose.

Single Bolt Tightening Mechanism:

Instead of a traditional worm screw, this clamp uses a single, robust bolt and nut assembly.

This design allows for significantly higher torque to be applied, creating a vastly superior clamping force. It is the preferred choice for high-pressure hoses, large-diameter pipes, or connections that are subject to strong vibrations.

Package of bolt hose clamp

1. bulk in carton

2.bag+carton+pallet

3.neutral box+neutral carton+pallet

4.plastic box+carton+pallet

5.customized color box+customized color carton
